Fiberglass Bullet Proof Panel UL Level 1 - Size 4'x8'

UL-100
$397.45
In stock
1
Product Details
Brand: ArmorCo Advanced Armor
Type: Bullet Proof Wall
Threat Level Rating: UL752 Level 1
Model: UL1 4X8
MPN: UL1FG4X8
Protection Against: Hand Guns
Country/Region of Manufacture: United States

Fiberglass Bullet Resistant Panel

Protection Level: UL Level 1 - Small Handgun Protection.

UL Level 1 Fiberglass Panels

Nominal Wt.: lbs/sq. ft: 2.9
Nominal Thickness: inches: 1/4"

Level: UL 1 - Hand Guns / Small Arms
Weapon: 9mm
Ammunition: FMJ / LC
Velocity ft/sec: 1090

Click here to view the specifications, MSDS and our Videos

Armorco SuperShield Fiberglass Bullet Resistant Panel. Made utilizing multiple layers of specially woven fiberglass with a proprietary resin system, the “Super Panels” are fortified in a press under extreme pressure using very high temperatures to create a Bullet Resistant “Super Panel”.

The “Super Panels” stop bullets by encapturing the ballistic projectiles in an innovative process called ply-delamination, and they also defeat the projectiles without the danger of ricocheting or spalling. This process makes ArmorCo SuperShield Panels the safest, most cost effective, and easy to work with ballistic protection available today.

Suggested uses: Protective wall systems, Potium furniture and doors, and vehicle armor to name a few.

PERFORMANCE LEVEL Underwriters Laboratory UL 752 11th Edition Standard for Bullet Resisting Equipment.

One hour fire rated to ASTM E119-00a Building Construction and Materials.

AMMUNITION TESTED 9mm full metal copper jacket with lead core, 124 Grain, 1175 fps, 3 shots

INSTALLATION Cut ArmorCo Opaque Fiberglass using ordinary carpentry tools. We suggest using a RemGrit® "Grit Edge“ saw blade. Install using self tapping drywall screws. Predrilling may be required on 1 3/16” and thicker material. Drill using high speed steel twist drill bits. We recommend that you incorporate 4“ overlap strips (battens) at seams. WARRANTY Materials and workmanship shall be warranted against defects for a period of two (2) years from the date of receipt at the project site.

Ballistic Panel Notes:

1. Standard Panel Sizes: 4' x 8' Other sizes can be made if needed so please request a quote.

VARIOUS SIZES AVAILABLE

[3’ X 8’] [3’ X 9’ ] [3’ X 10’]

[4’ X 8’] [4’ X 9]’ [4’ X 10’]

Water Jet Cutting Available

GET AN ONLINE QUOTE

Volume Discounts Available: Call Us Today - 1-440-992-2331
